iBotic is the high-capacity Cartesian spraying robot providing ultra-high finishing quality – on both the faces and edges of workpieces. What makes iBotic so special is that it can work simultaneously on pieces of different shape and thickness, with the conveyor either at standstill or on the move, in tracking mode.
READING BARRIER
The reading barrier, available in 2D version with 512 photodiodes and latest-generation 3D C-Vision version, ensures high-definition workpiece shape, size and position acquisition, enabling the control software to plot the best spraying trajectories.
2 SPRAYING ARMS
The duel 5 arm travel axes are what make this robot different from a normal sprayer: all axes are electronically controlled.
- CONVEYOR SYSTEM
iBotic is equipped with carbon fiber conveyor belt (CFB). The CFB configuration is ideal for guaranteeing paint recovery (thanks to the recovery and cleaning carriage), minimal solvent consumption and shorter maintenance times.
OVERSPRAY FILTRATION
This iBotic is equipped with an easily maintained and replaced two-stage paper filter. It also features a multiple output Plenum and fans to control the ventilation flows in the spraying zone.
SOFTWARE
For iBotic, Cefla Finishing has developed exclusive, state-of-the-art software able to decide and control all robot movements, from the simplest sequence of operations to the most sophisticated processing. This special control software allows user-friendly setting of all parameters.
Configuration:
- SPRAYING ARMS: 2
- CONVEYOR SYSTEM: CFB
- OVERSPRAY FILTRATION: dry filter
- Different working lengths
- Works as both a 5 axis robot spray machine and reciprocating spray machine
